Automotive Electrical and Network Diagnosis
Master advanced vehicle electrical forensics from digital storage oscilloscope capture to physical-layer CAN, LIN, and Ethernet network troubleshooting. Isolate elusive bus-down faults, parasitic wake-ups, and signal corruption with diagnostic precision.
Like Duolingo, but for Automotive Electrical and Network Diagnosis. Tomo turns the whole topic into a game you play five minutes a day, until it actually sticks.
25 levels across 3 sections, about 50 minutes end to end, roughly 10 days at five minutes a day. It moves through Waveform Forensics and Dynamic Circuit Testing; Controller Area Network (CAN) Forensics; and Sub-Buses, Advanced Networks, and Systemic Draw.
Free forever · No credit card · iPhone & Android
Key ideas in Automotive Electrical and Network Diagnosis
- Multimeters sample at 2 to 4 Hz and compute rolling RMS/average voltages, which mathematically hides a missing 50-microsecond tooth pulse
- A pulse-width trigger set below the expected square-wave duty cycle forces the scope to capture only runt pulses or dropped teeth
- Edge-fall triggers with single-sweep capture freeze the buffer the exact microsecond signal voltage plunges below threshold
- Inductive kick on fuel injectors and ignition coils reaches 60–400V within microseconds, clipping off-screen if attenuation and voltage divisions are scaled for 12V battery power
- Inspecting coil charge dwell and mechanical pintle seating requires millisecond time-bases to observe the current slope change and flyback tail
- Evaluating sequencing and cycle-to-cycle delivery across sequential injection demands a tens-of-milliseconds macro view
- AC coupling engages an internal series capacitor that blocks the high steady-state DC rail, centering the alternating component around zero volts
- Blocking the DC bias permits dropping vertical scale to 200 mV/div, making millivolt diode leakage humps visible rather than smashed against the display ceiling
- A blown negative or positive rectifier diode produces a distinctive periodic wave crest (>500 mV peak-to-peak) riding the alternator output
- Peak-detect samples at the ADC's maximum converter speed regardless of horizontal time-base, preventing narrow secondary ignition spikes from slipping between decimated screen pixels
- Infinite or color-graded persistence leaves visual ghost traces of intermittent CAN-bus arbitration collisions and sporadic secondary arc dropouts
- Standard sample-decimation downsamples by discarding points between screen pixels, rendering sub-microsecond ignition spikes invisible on wide time-bases
- Ground return currents from starter motors, alternators, and injectors produce transient potential drops across the chassis, creating phantom ground offsets
- Isolated or isolated-reference sensors (like planar zirconia O2 sensors) require probing directly across sensor signal and dedicated sensor ground return pins
- Connecting single-ended scope ground to noisy chassis metal superimposes charging and ignition return pulses directly onto the displayed sensor trace
- A multimeter injects microamps to millivolts during a resistance check, which is too low to produce a measurable Ohm's law drop (V = I * R) across strands with low surface-to-strand contact
You've tried the other tabs
Thirty open tabs. Four facts you actually kept.
You watched. You nodded. By Sunday it was gone.
One answer, then back to scrolling.
Eight weeks. You meant to finish. You didn't.
Tomo gives Automotive Electrical and Network Diagnosis the Duolingo treatment: levels, streaks, and quick quizzes that test what you just learned. That game loop is what the tabs above never had, so it's the one you actually finish.
Here's what playing it feels like
A real question from this course. Take your best guess.
How can you isolate an intermittent runt pulse or dropped tooth on a high-speed square-wave signal?
Get it right to open this lesson and 24 more in the app.
Where Automotive Electrical and Network Diagnosis takes you
- 1
Waveform Forensics and Dynamic Circuit Testing
- Catching Transient Faults with the Digital Storage Oscilloscope
- Dynamic Voltage Drop and In-Rush Current Profiling
- 2
Controller Area Network (CAN) Forensics
- CAN Physical Layer Decoding and Bus Topologies
- Isolating Bus-Down and Physical Faults
- Logic, Frame Integrity, and Traffic Contention
- 3
Sub-Buses, Advanced Networks, and Systemic Draw
- Diagnosing LIN Bus and Single-Wire Sub-Networks
- Automotive Ethernet, FlexRay, and Gateway Architecture
- Intermittent Wake-ups and Parasitic Current Triage
3 sections · 8 units · 25 levels. Built to play, not to enroll.
