Chizmachilik Asoslari
Texnik chizmalarni oʻqish va chizishning eng muhim qoidalari. Fazoviy tasavvurni shakllantirib, gʻoyalarni qogʻozda professional muhandis kabi aniq ifodalashni oʻrganing.
Like Duolingo, but for Chizmachilik Asoslari. Tomo turns the whole topic into a game you play five minutes a day, until it actually sticks.
A short one: 12 levels across 2 sections, about 24 minutes end to end, roughly 5 days at five minutes a day. It moves through Chiziqlar va Koʻrinishlar Tili and Aniq Oʻlcham va Ichki Tuzilish. It starts from scratch.
Free forever · No credit card · iPhone & Android
Key ideas in Chizmachilik Asoslari
- Chizmada buyumning koʻrinib turgan barcha tashqi va ichki qirralari tutash qalin chiziq bilan chiziladi
- Tutash qalin chiziq detalning asosiy shakli va chegarasini koʻrsatadi
- Boshqa ingichka yoki uzuq chiziqlar faqat yordamchi yoki koʻrinmas qismlar uchundir
- Koʻrinmaydigan qirra va yuzalar chizmada teng uzunlikdagi oraliqli shtrixli chiziqlar bilan belgilanadi
- Agar koʻrinmas qirralar chizilmasa, detalning orqasida teshik yoki oʻyiq borligi tushunarsiz qoladi
- Shtrix-punktir chiziq (chiziqcha va nuqta almashinuvi) aylanalarning markazi va simmetriya oʻqini koʻrsatish uchun xizmat qiladi
- Aylana markazi shtrix-punktir chiziqlarning aynan chiziqchalari kesishgan joyida belgilanadi, nuqtalarda emas
- H (hard) qalamlari qogʻozga kam grafit qoldiradi, ingichka va toza yordamchi chiziqlar uchun qulay
- B (black) qalamlari yumshoq boʻlib, qora va toʻq qalin chiziqlar beradi, lekin surkalsa qogʻozni kirlatadi
- HB qalami muvozanatli boʻlib, standart yozuv va oʻlchamlar uchun ishlatiladi
- Chizgʻich va burchaklikni bir-biriga tirab siljitish orqali mukammal parallel chiziqlar olinadi
- Burchaklik standart 90, 45 yoki 30/60 gradusli toʻgʻri burchaklarni transportirsiz aniq chizish imkonini beradi
- Qoʻlda erkin chizilgan chiziqlarda burchak va parallellik buziladi
- Perspektivada yoki burchak ostida chizilganda uzoqdagi chiziqlar kichikroq ko'rinib, o'lchamlar buziladi
- Ortogonal (to'g'ri burchak ostida) proyeksiyalanganda qirralar tekislikka o'zining haqiqiy o'lchami va nisbatida tushadi
- Ustaxonada detal yasash uchun aniq o'lchamlar olinadigan tekis chizmalar zarur
You've tried the other tabs
Thirty open tabs. Four facts you actually kept.
You watched. You nodded. By Sunday it was gone.
One answer, then back to scrolling.
Eight weeks. You meant to finish. You didn't.
Tomo gives Chizmachilik Asoslari the Duolingo treatment: levels, streaks, and quick quizzes that test what you just learned. That game loop is what the tabs above never had, so it's the one you actually finish.
Here's what playing it feels like
A real question from this course. Take your best guess.
Yogʻoch kubikning koʻzingizga toʻgʻridan-toʻgʻri koʻrinib turgan qirralarini chizish uchun qaysi chiziqni tanlaysiz?
Get it right to open this lesson and 11 more in the app.
Where Chizmachilik Asoslari takes you
- 1
Chiziqlar va Koʻrinishlar Tili
- Chizma asboblari va asosiy chiziqlar
- 3D buyumni 2D tekislikka oʻtkazish
- 2
Aniq Oʻlcham va Ichki Tuzilish
- Oʻlchamlarni toʻgʻri qoʻyish sirlari
- Ichki qismlarni ochish: Qirqim va kesimlar
2 sections · 4 units · 12 levels. Built to play, not to enroll.
