Key ideas in High-Performance LS Engine Blueprinting
- Aluminum LS blocks expand roughly 0.001" more across the main journals at operating temperature than cast-iron LS blocks
- Setting cold clearance too loose (e.g., above 0.0025") in an aluminum LS block causes excessive clearance at 200°F+ oil temps, leading to hot oil pressure collapse
- Cold main clearances for aluminum LS race engines are typically targeted tighter (around 0.0018"–0.0022") to land at the desired 0.0028"–0.0030" operating window
- Aftermarket forged LS crankshafts use large rolled fillet radii to increase fatigue strength under high-RPM reciprocating loads
- Standard production-style LS bearings have minimal edge chamfer and will ride directly on the fillet radius rather than the flat journal surface
- Performance LS bearings (such as King XP or Clevite H-series) feature a pronounced edge chamfer or narrowed width specifically engineered to clear these fillets
- Main studs exert different clamping forces and radial distortion on LS main bulkheads compared to factory TTY torque-angle bolts, requiring final fasteners and lubricant during bore measurement
- The deep-skirt LS architecture relies on horizontal cross-bolts that pull the side walls inward, drastically changing vertical and horizontal main bore roundness
- Torquing cylinder head studs/plates distorts the block deck and upper main bearing bulkheads, altering true roundness on high-performance LS blocks
- Centerless grinding or polishing errors can introduce tri-lobe out-of-round conditions that show constant diameter when measured only 90 degrees apart
- Above 7,000 RPM, reciprocating inertia creates massive cyclic deflection; any journal out-of-roundness disrupts the hydrodynamic wedge, leading to bearing metal-to-metal contact
- Checking main journals at 120-degree intervals confirms true circular geometry and adequate eccentric taper towards the parting lines
- The LS #3 main cap houses the thrust bearing flanges, which must have their upper and lower thrust faces perfectly coplanar to share axial loads evenly
- Snugging the cap lightly allows the bearing halves to slip when the crank is bumped fore and aft with a dead-blow hammer or pry bar
- Torquing the cap before bumping traps misalignment between the upper and lower thrust flanges, causing thrust bearing pinching and premature wipeout
- Final axial endplay (typically 0.003"–0.007" on an LS) is verified with a dial indicator only after final torque is applied
