DC Circuits and Signal Math
Calculate and measure DC voltages, graph dynamic signals, and wield differential equations and complex phasors to decode circuit behavior.
Like Duolingo, but for DC Circuits and Signal Math. Tomo turns the whole topic into a game you play five minutes a day, until it actually sticks.
A short one: 10 levels across 2 sections, about 20 minutes end to end, roughly 4 days at five minutes a day. It moves through Measuring DC and Sketching Waveforms and Predicting Circuit Transients and AC States. It starts from scratch.
Free forever · No credit card · iPhone & Android
Key ideas in DC Circuits and Signal Math
- Voltage acts as the electrical push while resistance opposes the flow of charge
- Higher resistance under a fixed voltage restricts the flow, causing current to drop proportionally (I = V/R)
- Ohm's law governs the direct relationship between voltage drop, current, and resistance
- Current cannot build up or disappear at an electrical junction
- Total current entering a node must equal total current leaving it (Kirchhoff's Current Law)
- Subtracting exiting currents from entering currents gives the balance flowing through remaining branches
- Tracing any complete closed path in a circuit returns to the starting potential energy (Kirchhoff's Voltage Law)
- Energy provided by sources equals energy lost across resistive elements in a closed loop
- The algebraic sum of voltage rises and drops around any closed loop is zero
- Series components share the exact same current
- Two resistors in series split the total source voltage in direct proportion to their resistance values
- Equal resistors in series split the applied voltage exactly in half, creating a stable midway reference voltage
- Voltage is a difference between two nodes, so a voltmeter connects in parallel across components without opening the circuit
- Current is a through-rate, so an ammeter must be inserted in series directly into the path by breaking the circuit
- Connecting an ammeter in parallel acts like a short circuit and can blow a fuse
- A step function u(t) is 0 before t = 0 and 1 after t = 0
