Real-World Circuit Behavior
Bridge the gap between theoretical schematics and functioning physical hardware. Learn how to diagnose live signals on a scope, stabilize op-amp circuits, and eliminate insidious board noise.
Like Duolingo, but for Real-World Circuit Behavior. Tomo turns the whole topic into a game you play five minutes a day, until it actually sticks.
A short one: 12 levels across 2 sections, about 24 minutes end to end, roughly 5 days at five minutes a day. It moves through Measuring and Conditioning Signals and Taming Hardware Imperfections. It assumes you already know the basics.
Free forever · No credit card · iPhone & Android
Key ideas in Real-World Circuit Behavior
- DC coupling forces the oscilloscope to display the full 12 V baseline offset.
- AC coupling inserts an internal series capacitor to strip out static DC bias.
- Blocking the high DC rail lets you zoom vertical sensitivity down to millivolts.
- Auto mode forces a trace redraw if no trigger arrives within a timeout.
- Normal mode waits indefinitely for a signal event before refreshing screen.
- Single mode stops memory acquisition right after capturing a lone transient.
- 10x mode adds an internal divider that drops tip capacitance down to ~10-15 pF.
- 1x mode presents 50-100 pF of capacitance that severely loads fast edge transitions.
- Lower tip capacitance avoids distorting signals at high-impedance test points.
- A long ground clip lead acts as an inductor that resonates with probe capacitance.
- Fast logic edges inject high di/dt that excites parasitic LC tank ringing.
- Replacing the ground alligator lead with a short spring tip suppresses the ringing.
- Deciding when to switch from DC to AC coupling to inspect tiny power supply ripple
- The 20 MHz limit attenuates out-of-band airborne RF pickup and broadcast noise.
- Low-pass filtering clarifies true in-band baseline noise on low-speed signals.
- The bandwidth limit rounds off fast sub-nanosecond rise times on logic edges.
You've tried the other tabs
Thirty open tabs. Four facts you actually kept.
You watched. You nodded. By Sunday it was gone.
One answer, then back to scrolling.
Eight weeks. You meant to finish. You didn't.
Tomo gives Real-World Circuit Behavior the Duolingo treatment: levels, streaks, and quick quizzes that test what you just learned. That game loop is what the tabs above never had, so it's the one you actually finish.
Here's what playing it feels like
A real question from this course. Take your best guess.
How does switching your oscilloscope channel to AC coupling remove a steady DC bias?
Get it right to open this lesson and 11 more in the app.
Where Real-World Circuit Behavior takes you
- 1
Measuring and Conditioning Signals
- Diagnosing Signals with an Oscilloscope
- Stabilizing Practical Op-Amp Stages
- 2
Taming Hardware Imperfections
- Sizing Real-World Passive Filters
- Grounding and Decoupling for Clean Circuits
2 sections · 4 units · 12 levels. Built to play, not to enroll.
You pick the voice
Real-World Circuit Behavior is taught in the The Professor style: clear, structured, thorough. Want a different feel? In the app you can spin up the same topic in any of Tomo's teaching styles. Same facts, totally different vibe.
