What you'll learn

Key ideas in Designing Your Own PCBs

  • A schematic shows only logical electrical connections, not physical placement or board geometry
  • Components can be arranged anywhere on the physical PCB layout regardless of where their symbols sit on the schematic page
  • Every circuit part needs a schematic symbol to define its electrical pins
  • Every part needs a footprint with copper pads that match its physical solder pins on the board
  • A symbol cannot be placed directly onto a physical board layout without an assigned footprint
  • Net labels allow separate wire segments sharing the exact same name to connect invisibly across the sheet
  • Using net labels eliminates cluttered 'wire spaghetti' across complex diagrams
  • PCB software treats any two pins tagged with the same net label as electrically joined
  • Reference designators use a letter-number code (like R1, C1, U1) to distinguish identical parts from each other
  • Values like '10k' or '0.1uF' describe electrical specs, but cannot uniquely identify which physical part goes where on the board
  • Every single physical part on the board needs its own unique reference designator
  • Dedicated power and ground symbols (like +5V or GND) create global nets that connect everywhere they appear
  • Using net labels to keep dense schematics clean without drawing crisscrossing wires
  • Any pin attached to a matching power or ground symbol joins that shared power rail across the entire board
  • Global power symbols keep diagrams readable by removing long return-path wires
  • Parts that interact with the physical outside world—like edge connectors, mounting holes, and user LEDs—have fixed locations dictated by the enclosure
