Key ideas in Building Working Circuits
- Saturating a BJT requires much more base current than active gain predicts
- A common rule of thumb uses an overdrive ratio of ten to one for saturation
- Insufficient base drive traps the BJT in linear mode where it burns heat
- Gate threshold voltage is only where conduction barely starts, not full on
- Datasheets specify RDS(on) test voltages needed to achieve minimal resistance
- Driving standard MOSFETs with 3.3V pins leaves the channel mostly pinched
- N-channel gates must be several volts above the source to conduct
- High-side N-channel sources float near the supply voltage when fully active
- Low-side switches keep the source tied to 0V ground for easy pin control
- A MOSFET gate acts like a discharged capacitor at the moment of switching
- Instantaneous charging draws a burst that can exceed GPIO current limits
- A low-value series component throttles peak current without stalling edge speed
- Transistors burn peak power when high voltage and high current overlap
- Weak gate drive stretches edge transition times across linear mode
- High PWM frequencies multiply the number of lossy transitions per second
- Collapsing magnetic fields in coils generate reverse voltage spikes far exceeding the supply rail.
