What you'll learn

Key ideas in Real-World Circuit Design

  • A trace behaves as an electrically long transmission line when signal rise time (tr) is shorter than the two-way propagation delay (2 * tpd)
  • On FR4, propagation delay is roughly 6 to 7 ps/mm (15 cm/ns), giving a ~1.33 ns round-trip flight time for a 10 cm line
  • When round-trip time exceeds rise time, reflections cannot settle during transition edges, requiring distributed transmission line modeling rather than lumped LC analysis
  • Above critical cutoff frequencies (typically tens of kHz), return current pathing is dominated by inductive reactance (omega * L) rather than ohmic resistance
  • Mutual inductance between signal and return forces high-frequency return current to crowd directly beneath the signal trace to minimize total loop area and enclosed magnetic flux
  • Series termination places a resistor at the driver such that R_source + R_driver equals Z0, absorbing receiver-reflected waves without drawing steady-state DC current
  • Parallel termination places R = Z0 at the receiver, terminating the initial wave immediately at the cost of continuous DC dissipation
  • AC termination inserts a series capacitor with the parallel resistor to block DC dissipation while presenting matching impedance at high-frequency edge transitions
  • A split forces high-frequency return current to divert around the void, creating a large parasitic inductive loop that radiates electromagnetic fields
  • The sudden impedance discontinuity at the boundary causes reflection, ringing, and edge degradation
  • A via barrel introduces excess series inductance (typically 0.5–1 nH) while antipads and pads introduce parasitic capacitance
  • Placing an adjacent ground stitching via within close proximity maintains a continuous reference loop for the vertical transition
  • Backdrilling unused via stubs eliminates resonance and reflection notches caused by open-circuit stub reflections
  • High-frequency return currents travel directly underneath the trace along the path of least inductance
  • Crossing a plane discontinuity forces return current into an expansive loop around the moat, creating a slot antenna that radiates and picks up EMI
  • A continuous, unbroken reference plane contains return currents directly beneath their signal lines
